THE RECON V6 line of products, including the DRIVER ELECTRONICS is warranted at ratings of IP66 and IP68 for a period of 1 year.
♦IP66, Water projected in powerful jets (12.5mm nozzle) against the enclosure from any direction shall have no harmful effects.
♦IP68*, The equipment is suitable for continuous immersion in water under conditions which shall be specified by the manufacturer. Normally, this will mean that the equipment is hermetically sealed.
§*Devices backed by an international standard rating of IP68 are deemed fit enough to withstand wind-blown dust, dirt and sand, and are resistant to submersion up to a maximum depth of 1.5m underwater for up to thirty minutes - TEXASBOARS extends this rating to 2 days (protected against temporary flood waters).
If a warranted device is subjected to such conditions it should be properly cleaned and inspected before further operation.
CORDS | CONNECTORS
6 feet - (blue connectors) connects the LED ENGINE to the DRIVER.
This cord should not be lengthened or modified.
The following Accessories Cord & BATTERY CORD may be lengthened at Check-Out.
2 feet - (black connectors) connects the driver to OPTIONAL ACCESSORIES such as switches or remote controls.
2 feet - connects from the Accessories Cord direct to the battery.
♦This cord may be lengthened up to 25 feet with 16 awg copper cord, 50 feet using 18 awg copper cord.
DRIVER | CORDS | CONNECTORS
Under no circumstances should the LED ENGINE be powered without the supplied DRIVER!
Catastrophic damage may/will occur!
♦ 1 LED ENGINE HOUSING & HEAT SINK: Comprised of Quarter inch Aluminum Aircraft Grade 6061-T6511. This grade of Aluminum is widely used for all types of industrial applications demanding greater strength along with lightweight and a high corrosion resistance.
♦ 2 ALL FASTENERS comprised of Stainless Steel 18-8 for extreme corrosion resistance.
♦ 3 CREE XPE-2 Series High Power Top Bin LEDs, Cree is the market-leading innovator in the LED industry. Cree has advanced the industry with the brightest and most efficient LEDs. Cree continues to upgrade their technology, and are able to offer the most lumens per watt for any high-brightness LED.
♦ 4 CARCLO TIR Focal OPtics, Focal Optics control the illumination pattern, either diffusing it or focusing it as the application requires.
♦ 5 Quarter Inch Polycarbonate Lens Cover with a tough gasket seal underneath to provide IP68 Rated Protection to Optics and LED ChipBoards.
♦ 6 Strong reliable bracket for attacthing the feeder light to tripods, CCTV Brackets and other similar devices for easy fast deployment and portability as well as permannet outdoor installation. This bracket fits standard post pattern (1/4-20) same as Cameras, Camcorders and Security Cameras.
